In this tutorial, we build an end-to-end cognitive complexity analysis workflow using complexity. We start measuring complexity directly from raw code strings, then extend the same analysis to individual files and the entire project directory. Additionally, we generate machine-readable reports, normalize them into structured dataframes, and visualize complexity distributions to understand how decision depth accumulates across tasks. By treating cognitive complexity as a measurable engineering signal, we show how it can be naturally integrated into everyday Python development and quality checking. check it out full code here.
!pip -q install complexipy pandas matplotlib
import os
import json
import textwrap
import subprocess
from pathlib import Path
import pandas as pd
import matplotlib.pyplot as plt
from complexipy import code_complexity, file_complexity
print("✅ Installed complexipy and dependencies")We set up the environment by installing the required libraries and importing all the dependencies required for analysis and visualization. We ensure that the notebook is completely self-contained and ready to run in Google Colab without external setup. It forms the backbone of the execution of everything that follows.
snippet = """
def score_orders(orders):
total = 0
for o in orders:
if o.get("valid"):
if o.get("priority"):
if o.get("amount", 0) > 100:
total += 3
else:
total += 2
else:
if o.get("amount", 0) > 100:
total += 2
else:
total += 1
else:
total -= 1
return total
"""
res = code_complexity(snippet)
print("=== Code string complexity ===")
print("Overall complexity:", res.complexity)
print("Functions:")
for f in res.functions:
print(f" - {f.name}: {f.complexity} (lines {f.line_start}-{f.line_end})")We start by analyzing a raw Python code string to understand cognitive complexity at the function level. We directly observe how nested conditionals and control flows contribute to complexity. This helps us validate the basic behavior of the complexity before scaling it to real files.
root = Path("toy_project")
src = root / "src"
tests = root / "tests"
src.mkdir(parents=True, exist_ok=True)
tests.mkdir(parents=True, exist_ok=True)
(src / "__init__.py").write_text("")
(tests / "__init__.py").write_text("")
(src / "simple.py").write_text(textwrap.dedent("""
def add(a, b):
return a + b
def safe_div(a, b):
if b == 0:
return None
return a / b
""").strip() + "n")
(src / "legacy_adapter.py").write_text(textwrap.dedent("""
def legacy_adapter(x, y):
if x and y:
if x > 0:
if y > 0:
return x + y
else:
return x - y
else:
if y > 0:
return y - x
else:
return -(x + y)
return 0
""").strip() + "n")
(src / "engine.py").write_text(textwrap.dedent("""
def route_event(event):
kind = event.get("kind")
payload = event.get("payload", {})
if kind == "A":
if payload.get("x") and payload.get("y"):
return _handle_a(payload)
return None
elif kind == "B":
if payload.get("flags"):
return _handle_b(payload)
else:
return None
elif kind == "C":
for item in payload.get("items", ()):
if item.get("enabled"):
if item.get("mode") == "fast":
_do_fast(item)
else:
_do_safe(item)
return True
else:
return None
def _handle_a(p):
total = 0
for v in p.get("vals", ()):
if v > 10:
total += 2
else:
total += 1
return total
def _handle_b(p):
score = 0
for f in p.get("flags", ()):
if f == "x":
score += 1
elif f == "y":
score += 2
else:
score -= 1
return score
def _do_fast(item):
return item.get("id")
def _do_safe(item):
if item.get("id") is None:
return None
return item.get("id")
""").strip() + "n")
(tests / "test_engine.py").write_text(textwrap.dedent("""
from src.engine import route_event
def test_route_event_smoke():
assert route_event({"kind": "A", "payload": {"x": 1, "y": 2, "vals": (1, 20)}}) == 3
""").strip() + "n")
print(f"✅ Created project at: {root.resolve()}")We programmatically create a small but realistic Python project with several modules and test files. We intentionally include different control-flow patterns to create meaningful differences in complexity. check it out full code here.
engine_path = src / "engine.py"
file_res = file_complexity(str(engine_path))
print("n=== File complexity (Python API) ===")
print("Path:", file_res.path)
print("File complexity:", file_res.complexity)
for f in file_res.functions:
print(f" - {f.name}: {f.complexity} (lines {f.line_start}-{f.line_end})")
MAX_ALLOWED = 8
def run_complexipy_cli(project_dir: Path, max_allowed: int = 8):
cmd = (
"complexipy",
".",
"--max-complexity-allowed", str(max_allowed),
"--output-json",
"--output-csv",
)
proc = subprocess.run(cmd, cwd=str(project_dir), capture_output=True, text=True)
preferred_csv = project_dir / "complexipy.csv"
preferred_json = project_dir / "complexipy.json"
csv_candidates = ()
json_candidates = ()
if preferred_csv.exists():
csv_candidates.append(preferred_csv)
if preferred_json.exists():
json_candidates.append(preferred_json)
csv_candidates += list(project_dir.glob("*.csv")) + list(project_dir.glob("**/*.csv"))
json_candidates += list(project_dir.glob("*.json")) + list(project_dir.glob("**/*.json"))
def uniq(paths):
seen = set()
out = ()
for p in paths:
p = p.resolve()
if p not in seen and p.is_file():
seen.add(p)
out.append(p)
return out
csv_candidates = uniq(csv_candidates)
json_candidates = uniq(json_candidates)
def pick_best(paths):
if not paths:
return None
paths = sorted(paths, key=lambda p: p.stat().st_mtime, reverse=True)
return paths(0)
return proc.returncode, pick_best(csv_candidates), pick_best(json_candidates)
rc, csv_report, json_report = run_complexipy_cli(root, MAX_ALLOWED)We analyze a real source file using the Python API, then run complex CLI on the entire project. We run the CLI from the correct working directory to generate reports reliably. This step combines native API usage with a production-style static analysis workflow.
df = None
if csv_report and csv_report.exists():
df = pd.read_csv(csv_report)
elif json_report and json_report.exists():
data = json.loads(json_report.read_text())
if isinstance(data, list):
df = pd.DataFrame(data)
elif isinstance(data, dict):
if "files" in data and isinstance(data("files"), list):
df = pd.DataFrame(data("files"))
elif "results" in data and isinstance(data("results"), list):
df = pd.DataFrame(data("results"))
else:
df = pd.json_normalize(data)
if df is None:
raise RuntimeError("No report produced")
def explode_functions_table(df_in):
if "functions" in df_in.columns:
tmp = df_in.explode("functions", ignore_index=True)
if tmp("functions").notna().any() and isinstance(tmp("functions").dropna().iloc(0), dict):
fn = pd.json_normalize(tmp("functions"))
base = tmp.drop(columns=("functions"))
return pd.concat((base.reset_index(drop=True), fn.reset_index(drop=True)), axis=1)
return tmp
return df_in
fn_df = explode_functions_table(df)
col_map = {}
for c in fn_df.columns:
lc = c.lower()
if lc in ("path", "file", "filename", "module"):
col_map(c) = "path"
if ("function" in lc and "name" in lc) or lc in ("function", "func", "function_name"):
col_map(c) = "function"
if lc == "name" and "function" not in fn_df.columns:
col_map(c) = "function"
if "complexity" in lc and "allowed" not in lc and "max" not in lc:
col_map(c) = "complexity"
if lc in ("line_start", "linestart", "start_line", "startline"):
col_map(c) = "line_start"
if lc in ("line_end", "lineend", "end_line", "endline"):
col_map(c) = "line_end"
fn_df = fn_df.rename(columns=col_map)We load the generated complexity reports into pandas and normalize them into a function-level table. We handle multiple possible report schemas to keep the workflow robust. This structured representation allows us to reason about complexity using standard data analysis tools.
if "complexity" in fn_df.columns:
fn_df("complexity") = pd.to_numeric(fn_df("complexity"), errors="coerce")
plt.figure()
fn_df("complexity").dropna().plot(kind="hist", bins=20)
plt.title("Cognitive Complexity Distribution (functions)")
plt.xlabel("complexity")
plt.ylabel("count")
plt.show()
def refactor_hints(complexity):
if complexity >= 20:
return (
"Split into smaller pure functions",
"Replace deep nesting with guard clauses",
"Extract complex boolean predicates"
)
if complexity >= 12:
return (
"Extract inner logic into helpers",
"Flatten conditionals",
"Use dispatch tables"
)
if complexity >= 8:
return (
"Reduce nesting",
"Early returns"
)
return ("Acceptable complexity")
if "complexity" in fn_df.columns and "function" in fn_df.columns:
for _, r in fn_df.sort_values("complexity", ascending=False).head(8).iterrows():
cx = float(r("complexity")) if pd.notna(r("complexity")) else None
if cx is None:
continue
print(r("function"), cx, refactor_hints(cx))
print("✅ Tutorial complete.")We visualize the distribution of cognitive complexity and derive refactoring guidance from the numerical range. We convert abstract complexity scores into concrete engineering actions. This closes the loop by linking measurements directly to maintenance decisions.
In conclusion, we presented a practical, reproducible pipeline for auditing cognitive complexity in Python projects using Complexity. We demonstrated how we can move from ad-hoc inspection to data-driven reasoning about code structure, identifying high-risk tasks and providing actionable refactoring guidance based on quantitative thresholds. Workflows allow us to reason quickly about maintainability, consistently enforce complexity budgets, and grow the codebase with clarity and confidence rather than relying solely on intuition.
