In this tutorial, we present an advanced, practical tutorial that demonstrates how we use Crisp Constructing and executing non-trivial quantum algorithms. We walk through the core QURISP abstraction for quantum data, construct entangled states, and then sequentially implement Grover’s search with automated uncomputation, quantum phase estimation, and a full QoA workflow for the MaxCut problem. Additionally, we focus on writing expressive, high-level quantum programs while letting Qrisp manage circuit construction, control logic, and reversibility behind the scenes. check it out full code here.
import sys, subprocess, math, random, textwrap, time
def _pip_install(pkgs):
cmd = (sys.executable, "-m", "pip", "install", "-q") + pkgs
subprocess.check_call(cmd)
print("Installing dependencies (qrisp, networkx, matplotlib, sympy)...")
_pip_install(("qrisp", "networkx", "matplotlib", "sympy"))
print("✓ Installedn")
import numpy as np
import networkx as nx
import matplotlib.pyplot as plt
from qrisp import (
QuantumVariable, QuantumFloat, QuantumChar,
h, z, x, cx, p,
control, QFT, multi_measurement,
auto_uncompute
)
from qrisp.qaoa import (
QAOAProblem, RX_mixer,
create_maxcut_cost_operator, create_maxcut_cl_cost_function
)
from qrisp.grover import diffuserWe start by setting up the execution environment with the minimum scientific stack needed to run quantum experiments and installing Qrisp. We import core Qarisp primitives that allow us to represent quantum data types, gates, and control flow. We also create optimization and grower utilities that will later enable variable algorithms and dimension amplification. check it out full code here.
def banner(title):
print("n" + "="*90)
print(title)
print("="*90)
def topk_probs(prob_dict, k=10):
items = sorted(prob_dict.items(), key=lambda kv: kv(1), reverse=True)(:k)
return items
def print_topk(prob_dict, k=10, label="Top outcomes"):
items = topk_probs(prob_dict, k=k)
print(label)
for state, prob in items:
print(f" {state}: {prob:.4f}")
def bitstring_to_partition(bitstring):
left = (i for i, b in enumerate(bitstring) if b == "0")
right = (i for i, b in enumerate(bitstring) if b == "1")
return left, right
def classical_maxcut_cost(G, bitstring):
s = set(i for i, b in enumerate(bitstring) if b == "0")
cost = 0
for u, v in G.edges():
if (u in s) != (v in s):
cost += 1
return cost
banner("SECTION 1 — Qrisp Core: QuantumVariable, QuantumSession, GHZ State")
def GHZ(qv):
h(qv(0))
for i in range(1, qv.size):
cx(qv(0), qv(i))
qv = QuantumVariable(5)
GHZ(qv)
print("Circuit (QuantumSession):")
print(qv.qs)
print("nState distribution (printing QuantumVariable triggers a measurement-like dict view):")
print(qv)
meas = qv.get_measurement()
print_topk(meas, k=6, label="nMeasured outcomes (approx.)")
qch = QuantumChar()
h(qch(0))
print("nQuantumChar measurement sample:")
print_topk(qch.get_measurement(), k=8)We define utility functions that help us inspect probability distributions, interpret bitstrings, and evaluate classical costs for comparison with quantum outputs. We then construct a GHZ scenario to demonstrate how Qrisp handles entanglement and circuit structure through high-level abstractions. We also demonstrate typed quantum data using quantumchar, showing how symbolic quantum values can be manipulated and measured. check it out full code here.
banner("SECTION 2 — Grover + auto_uncompute: Solve x^2 = 0.25 (QuantumFloat oracle)")
@auto_uncompute
def sqrt_oracle(qf):
cond = (qf * qf == 0.25)
z(cond)
qf = QuantumFloat(3, -1, signed=True)
n = qf.size
iterations = int(0.25 * math.pi * math.sqrt((2**n) / 2))
print(f"QuantumFloat qubits: {n} | Grover iterations: {iterations}")
h(qf)
for _ in range(iterations):
sqrt_oracle(qf)
diffuser(qf)
print("nGrover result distribution (QuantumFloat prints decoded values):")
print(qf)
qf_meas = qf.get_measurement()
print_topk(qf_meas, k=10, label="nTop measured values (decoded by QuantumFloat):")We implement the Grover oracle using automatic uncomputation, which allows us to express reversible logic without manually clearing intermediate states. We apply amplitude amplification to the quantumfloat search space to solve a simple nonlinear equation using quantum search. We finally inspect the resulting measurement distribution to identify the most probable solutions produced by Grover’s algorithm. check it out full code here.
banner("SECTION 3 — Quantum Phase Estimation (QPE): Controlled U + inverse QFT")
def QPE(psi: QuantumVariable, U, precision: int):
res = QuantumFloat(precision, -precision, signed=False)
h(res)
for i in range(precision):
with control(res(i)):
for _ in range(2**i):
U(psi)
QFT(res, inv=True)
return res
def U_example(psi):
phi_1 = 0.5
phi_2 = 0.125
p(phi_1 * 2 * np.pi, psi(0))
p(phi_2 * 2 * np.pi, psi(1))
psi = QuantumVariable(2)
h(psi)
res = QPE(psi, U_example, precision=3)
print("Joint measurement of (psi, phase_estimate):")
mm = multi_measurement((psi, res))
items = sorted(mm.items(), key=lambda kv: (-kv(1), str(kv(0))))
for (psi_bits, phase_val), prob in items:
print(f" psi={psi_bits} phase≈{phase_val} prob={prob:.4f}")We build a complete quantum phase estimation pipeline by combining controlled unitary applications with the inverse quantum Fourier transform. We demonstrate how phase information is encoded into a quantum register with tunable precision using quantumfloat. We then jointly measure the system and phase regressors to interpret the estimated eigenphases. check it out full code here.
banner("SECTION 4 — QAOA MaxCut: QAOAProblem.run + best cut visualization")
G = nx.erdos_renyi_graph(6, 0.65, seed=133)
while G.number_of_edges() < 5:
G = nx.erdos_renyi_graph(6, 0.65, seed=random.randint(0, 9999))
print(f"Graph: |V|={G.number_of_nodes()} |E|={G.number_of_edges()}")
print("Edges:", list(G.edges())(:12), "..." if G.number_of_edges() > 12 else "")
qarg = QuantumVariable(G.number_of_nodes())
qaoa_maxcut = QAOAProblem(
cost_operator=create_maxcut_cost_operator(G),
mixer=RX_mixer,
cl_cost_function=create_maxcut_cl_cost_function(G),
)
depth = 3
max_iter = 25
t0 = time.time()
results = qaoa_maxcut.run(qarg, depth=depth, max_iter=max_iter)
t1 = time.time()
print(f"nQAOA finished in {t1 - t0:.2f}s (depth={depth}, max_iter={max_iter})")
print("Returned measurement distribution size:", len(results))
cl_cost = create_maxcut_cl_cost_function(G)
print("nTop 8 candidate cuts (bitstring, prob, cost):")
top8 = sorted(results.items(), key=lambda kv: kv(1), reverse=True)(:8)
for bitstr, prob in top8:
cost_val = cl_cost({bitstr: 1})
print(f" {bitstr} prob={prob:.4f} cut_edges≈{cost_val}")
best_bitstr = top8(0)(0)
best_cost = classical_maxcut_cost(G, best_bitstr)
left, right = bitstring_to_partition(best_bitstr)
print(f"nMost likely solution: {best_bitstr}")
print(f"Partition 0-side: {left}")
print(f"Partition 1-side: {right}")
print(f"Classical crossing edges (verified): {best_cost}")
pos = nx.spring_layout(G, seed=42)
node_colors = ("#6929C4" if best_bitstr(i) == "0" else "#20306f" for i in G.nodes())
plt.figure(figsize=(6.5, 5.2))
nx.draw(
G, pos,
with_labels=True,
node_color=node_colors,
node_size=900,
font_color="white",
edge_color="#CCCCCC",
)
plt.title(f"QAOA MaxCut (best bitstring = {best_bitstr}, cut={best_cost})")
plt.show()
banner("DONE — You now have Grover + QPE + QAOA workflows running in Qrisp on Colab ✅")
print("Tip: Try increasing QAOA depth, changing the graph, or swapping mixers (RX/RY/XY) to explore behavior.")We formulate the MaxCut problem as a QAOA example using Qrisp’s problem-oriented abstraction and run a hybrid quantum-classical optimization loop. We analyze the returned probability distributions to identify high-quality cut candidates and validate them with a classical cost function. We conclude by visualizing the best cut, connecting abstract quantum results to an intuitive graph structure.
We conclude by showing how a single, consistent Qrisp workflow allows us to go from low-level quantum state preparation to modern variational algorithms used in near-term quantum computing. By combining problem-oriented abstractions such as automated uncomputation, controlled operations, and QAOAProblem, we demonstrate how we rapidly prototype and experiment with advanced quantum algorithms. Furthermore, this tutorial establishes a strong foundation for extending our work to deeper circuits, alternative mixers and cost functions, and more complex quantum-classical hybrid experiments.
